of 682 results found
View:

Filters

RRV4Q4-65D-R7 RRV4Q4-65D-R7
20-port sector antenna,4 x 694-960 MHz (R1-R2), and 8 x 1695-2690 MHz (Y1-Y4) 65° HPBW, 8 x 2300-3800 MHz (P1), 90° HPBW, 7 x RET
RRV4Q4-65D-R7
  • Product type: Beamforming antenna | Sector antenna
  • Operating frequency band range: 1427 – 2700 MHz | 3100 – 5000 MHz | 575 – 960 MHz
  • Horizontal beamwidth: 65° | 90°
  • Length size: 3.0 m (10 ft)+
  • Width/diameter: 458 – 498 mm
  • Rf connector interface: 4.3-10 Female | M-LOC
  • Rf connector quantity, total: 20
  • Rf connector quantity, high band: 8
  • Rf connector quantity, mid band: 8
  • Rf connector quantity, low band: 4
SpecificationsSpecs
RRV4Q4-65D-R7
  • Product type: Beamforming antenna | Sector antenna
  • Operating frequency band range: 1427 – 2700 MHz | 3100 – 5000 MHz | 575 – 960 MHz
  • Horizontal beamwidth: 65° | 90°
  • Length size: 3.0 m (10 ft)+
  • Width/diameter: 458 – 498 mm
  • Rf connector interface: 4.3-10 Female | M-LOC
  • Rf connector quantity, total: 20
  • Rf connector quantity, high band: 8
  • Rf connector quantity, mid band: 8
  • Rf connector quantity, low band: 4
RRV4Q4-65D-R7V2 RRV4Q4-65D-R7V2
20-port sector antenna,4 x 694-960 MHz (R1-R2), and 8 x 1695-2690 MHz (Y1-Y4) 65° HPBW, 8 x 2300-3800 MHz (P1), 90° HPBW, 7 x RET
RRV4Q4-65D-R7V2
  • Product type: Beamforming antenna | Sector antenna
  • Operating frequency band range: 1427 – 2700 MHz | 3100 – 5000 MHz | 575 – 960 MHz
  • Horizontal beamwidth: 65° | 90°
  • Length size: 3.0 m (10 ft)+
  • Width/diameter: 458 – 498 mm
  • Rf connector interface: 4.3-10 Female
  • Rf connector quantity, total: 20
  • Rf connector quantity, high band: 8
  • Rf connector quantity, mid band: 8
  • Rf connector quantity, low band: 4
SpecificationsSpecs
RRV4Q4-65D-R7V2
  • Product type: Beamforming antenna | Sector antenna
  • Operating frequency band range: 1427 – 2700 MHz | 3100 – 5000 MHz | 575 – 960 MHz
  • Horizontal beamwidth: 65° | 90°
  • Length size: 3.0 m (10 ft)+
  • Width/diameter: 458 – 498 mm
  • Rf connector interface: 4.3-10 Female
  • Rf connector quantity, total: 20
  • Rf connector quantity, high band: 8
  • Rf connector quantity, mid band: 8
  • Rf connector quantity, low band: 4
RRV4Q4-65D-R7V4 RRV4Q4-65D-R7V4
20-port sector antenna,4 x 694-960 MHz (R1-R2), and 8 x 1695-2690 MHz (Y1-Y4), 65° HPBW, 8 x 2300-3800 MHz (P1), 90° HPBW, 7 x RET
RRV4Q4-65D-R7V4
  • Product type: Beamforming antenna | Sector antenna
  • Operating frequency band range: 1427 – 2700 MHz | 3100 – 5000 MHz | 575 – 960 MHz
  • Horizontal beamwidth: 65° | 90°
  • Length size: 3.0 m (10 ft)+
  • Width/diameter: 458 – 498 mm
  • Rf connector interface: 4.3-10 Female | MQ4 | MQ5
  • Rf connector quantity, total: 20
  • Rf connector quantity, high band: 8
  • Rf connector quantity, mid band: 8
  • Rf connector quantity, low band: 4
SpecificationsSpecs
RRV4Q4-65D-R7V4
  • Product type: Beamforming antenna | Sector antenna
  • Operating frequency band range: 1427 – 2700 MHz | 3100 – 5000 MHz | 575 – 960 MHz
  • Horizontal beamwidth: 65° | 90°
  • Length size: 3.0 m (10 ft)+
  • Width/diameter: 458 – 498 mm
  • Rf connector interface: 4.3-10 Female | MQ4 | MQ5
  • Rf connector quantity, total: 20
  • Rf connector quantity, high band: 8
  • Rf connector quantity, mid band: 8
  • Rf connector quantity, low band: 4
RRV4S4-65D-R5 RRV4S4-65D-R5
20-port sector antenna, 4x 694–960, 8x 1695–2690 MHz, 65° HPBW and 8x 3300-3800 MHz, 90° HPBW, 5x RET
RRV4S4-65D-R5
  • Product type: Beamforming antenna | Sector antenna
  • Operating frequency band range: 1427 – 2700 MHz | 3100 – 5000 MHz | 575 – 960 MHz
  • Horizontal beamwidth: 65° | 90°
  • Length size: 2.5 m (8 ft)
  • Width/diameter: 458 – 498 mm
  • Rf connector interface: 4.3-10 Female | M-LOC
  • Rf connector quantity, total: 20
  • Rf connector quantity, high band: 8
  • Rf connector quantity, mid band: 8
  • Rf connector quantity, low band: 4
SpecificationsSpecs
RRV4S4-65D-R5
  • Product type: Beamforming antenna | Sector antenna
  • Operating frequency band range: 1427 – 2700 MHz | 3100 – 5000 MHz | 575 – 960 MHz
  • Horizontal beamwidth: 65° | 90°
  • Length size: 2.5 m (8 ft)
  • Width/diameter: 458 – 498 mm
  • Rf connector interface: 4.3-10 Female | M-LOC
  • Rf connector quantity, total: 20
  • Rf connector quantity, high band: 8
  • Rf connector quantity, mid band: 8
  • Rf connector quantity, low band: 4
RRVV-33B-R2 RRVV-33B-R2
8-port multiband sector antenna, 4x 694-960 and 4 x 1695-2690 MHz, 33° HPBW, 2x RET
RRVV-33B-R2
  • Product type: Sector antenna
  • Operating frequency band range: 1427 – 2700 MHz | 575 – 960 MHz
  • Horizontal beamwidth: 33°
  • Length size: 2.0 m (6 ft)
  • Width/diameter: > 499 mm
  • Rf connector interface: 4.3-10 Female
  • Rf connector quantity, total: 8
  • Rf connector quantity, mid band: 4
  • Rf connector quantity, low band: 4
SpecificationsSpecs
RRVV-33B-R2
  • Product type: Sector antenna
  • Operating frequency band range: 1427 – 2700 MHz | 575 – 960 MHz
  • Horizontal beamwidth: 33°
  • Length size: 2.0 m (6 ft)
  • Width/diameter: > 499 mm
  • Rf connector interface: 4.3-10 Female
  • Rf connector quantity, total: 8
  • Rf connector quantity, mid band: 4
  • Rf connector quantity, low band: 4
RRVV-65A-R2N43 RRVV-65A-R2N43
8-port sector antenna, 4 x 694–960 and 4 x 1695–2690 MHz, 65° HPBW, 2x RET
RRVV-65A-R2N43
  • Product type: Sector antenna
  • Operating frequency band range: 1427 – 2700 MHz | 575 – 960 MHz
  • Horizontal beamwidth: 65°
  • Length size: 1.3 m (4 ft)
  • Width/diameter: 354 – 457 mm
  • Rf connector interface: 4.3-10 Female
  • Rf connector quantity, total: 8
  • Rf connector quantity, mid band: 4
  • Rf connector quantity, low band: 4
SpecificationsSpecs
RRVV-65A-R2N43
  • Product type: Sector antenna
  • Operating frequency band range: 1427 – 2700 MHz | 575 – 960 MHz
  • Horizontal beamwidth: 65°
  • Length size: 1.3 m (4 ft)
  • Width/diameter: 354 – 457 mm
  • Rf connector interface: 4.3-10 Female
  • Rf connector quantity, total: 8
  • Rf connector quantity, mid band: 4
  • Rf connector quantity, low band: 4
RRVV-65A-R4VB RRVV-65A-R4VB
8-port sector antenna, 4x 698–960 and 4x 1710–2690 MHz, 65°HPBW, 4x RET
RRVV-65A-R4VB
  • Product type: Sector antenna
  • Operating frequency band range: 1427 – 2700 MHz | 575 – 960 MHz
  • Horizontal beamwidth: 65°
  • Length size: 1.3 m (4 ft)
  • Width/diameter: 458 – 498 mm
  • Rf connector interface: 4.3-10 Female
  • Rf connector quantity, total: 8
  • Rf connector quantity, high band: 0
  • Rf connector quantity, mid band: 4
  • Rf connector quantity, low band: 4
SpecificationsSpecs
RRVV-65A-R4VB
  • Product type: Sector antenna
  • Operating frequency band range: 1427 – 2700 MHz | 575 – 960 MHz
  • Horizontal beamwidth: 65°
  • Length size: 1.3 m (4 ft)
  • Width/diameter: 458 – 498 mm
  • Rf connector interface: 4.3-10 Female
  • Rf connector quantity, total: 8
  • Rf connector quantity, high band: 0
  • Rf connector quantity, mid band: 4
  • Rf connector quantity, low band: 4
RRVV-65B-R2N43 RRVV-65B-R2N43
8-port sector antenna, 4 x 694–960 and 4 x 1695–2690 MHz, 65° HPBW, 2x RET
RRVV-65B-R2N43
  • Product type: Sector antenna
  • Operating frequency band range: 1427 – 2700 MHz | 575 – 960 MHz
  • Horizontal beamwidth: 65°
  • Length size: 2.0 m (6 ft)
  • Width/diameter: 354 – 457 mm
  • Rf connector interface: 4.3-10 Female
  • Rf connector quantity, total: 8
  • Rf connector quantity, mid band: 4
  • Rf connector quantity, low band: 4
SpecificationsSpecs
RRVV-65B-R2N43
  • Product type: Sector antenna
  • Operating frequency band range: 1427 – 2700 MHz | 575 – 960 MHz
  • Horizontal beamwidth: 65°
  • Length size: 2.0 m (6 ft)
  • Width/diameter: 354 – 457 mm
  • Rf connector interface: 4.3-10 Female
  • Rf connector quantity, total: 8
  • Rf connector quantity, mid band: 4
  • Rf connector quantity, low band: 4
RRVV-65B-R2VB-V2 RRVV-65B-R2VB-V2
8-port sector antenna, 4x 694–960 and 4x 1695–2690 MHz, 65° HPBW, 2x RET
RRVV-65B-R2VB-V2
  • Product type: Sector antenna
  • Operating frequency band range: 1427 – 2700 MHz | 575 – 960 MHz
  • Horizontal beamwidth: 65°
  • Length size: 2.0 m (6 ft)
  • Width/diameter: > 499 mm
  • Rf connector interface: 4.3-10 Female
  • Rf connector quantity, total: 8
  • Rf connector quantity, mid band: 4
  • Rf connector quantity, low band: 4
SpecificationsSpecs
RRVV-65B-R2VB-V2
  • Product type: Sector antenna
  • Operating frequency band range: 1427 – 2700 MHz | 575 – 960 MHz
  • Horizontal beamwidth: 65°
  • Length size: 2.0 m (6 ft)
  • Width/diameter: > 499 mm
  • Rf connector interface: 4.3-10 Female
  • Rf connector quantity, total: 8
  • Rf connector quantity, mid band: 4
  • Rf connector quantity, low band: 4
RRVV-65B-R4-V2 RRVV-65B-R4-V2
8-port sector antenna, 4x 694–960 and 4x 1695–2690 MHz, 65° HPBW, 4x RET
RRVV-65B-R4-V2
  • Product type: Sector antenna
  • Operating frequency band range: 1427 – 2700 MHz | 575 – 960 MHz
  • Horizontal beamwidth: 65°
  • Length size: 2.0 m (6 ft)
  • Width/diameter: 458 – 498 mm
  • Rf connector interface: 4.3-10 Female
  • Rf connector quantity, total: 8
  • Rf connector quantity, high band: 4
  • Rf connector quantity, mid band: 0
  • Rf connector quantity, low band: 4
SpecificationsSpecs
RRVV-65B-R4-V2
  • Product type: Sector antenna
  • Operating frequency band range: 1427 – 2700 MHz | 575 – 960 MHz
  • Horizontal beamwidth: 65°
  • Length size: 2.0 m (6 ft)
  • Width/diameter: 458 – 498 mm
  • Rf connector interface: 4.3-10 Female
  • Rf connector quantity, total: 8
  • Rf connector quantity, high band: 4
  • Rf connector quantity, mid band: 0
  • Rf connector quantity, low band: 4
RRVV-65B-R4-V4 RRVV-65B-R4-V4
8-port sector antenna, 4x 694–960 and 4x 1695–2690 MHz, 65° HPBW, 4x RET
RRVV-65B-R4-V4
  • Product type: Sector antenna
  • Operating frequency band range: 1427 – 2700 MHz | 575 – 960 MHz
  • Horizontal beamwidth: 65°
  • Length size: 2.0 m (6 ft)
  • Width/diameter: 458 – 498 mm
  • Rf connector interface: 4.3-10 Female
  • Rf connector quantity, total: 8
  • Rf connector quantity, high band: 0
  • Rf connector quantity, mid band: 4
  • Rf connector quantity, low band: 4
SpecificationsSpecs
RRVV-65B-R4-V4
  • Product type: Sector antenna
  • Operating frequency band range: 1427 – 2700 MHz | 575 – 960 MHz
  • Horizontal beamwidth: 65°
  • Length size: 2.0 m (6 ft)
  • Width/diameter: 458 – 498 mm
  • Rf connector interface: 4.3-10 Female
  • Rf connector quantity, total: 8
  • Rf connector quantity, high band: 0
  • Rf connector quantity, mid band: 4
  • Rf connector quantity, low band: 4
RRVV-65B-R4VB-V2 RRVV-65B-R4VB-V2
8-port sector antenna, 4x 698–960 and 4x 1710–2690 MHz, 65°HPBW, 4x RET
RRVV-65B-R4VB-V2
  • Product type: Sector antenna
  • Operating frequency band range: 1427 – 2700 MHz | 575 – 960 MHz
  • Horizontal beamwidth: 65°
  • Length size: 2.0 m (6 ft)
  • Width/diameter: 458 – 498 mm
  • Rf connector interface: 4.3-10 Female
  • Rf connector quantity, total: 8
  • Rf connector quantity, high band: 0
  • Rf connector quantity, mid band: 4
  • Rf connector quantity, low band: 4
SpecificationsSpecs
RRVV-65B-R4VB-V2
  • Product type: Sector antenna
  • Operating frequency band range: 1427 – 2700 MHz | 575 – 960 MHz
  • Horizontal beamwidth: 65°
  • Length size: 2.0 m (6 ft)
  • Width/diameter: 458 – 498 mm
  • Rf connector interface: 4.3-10 Female
  • Rf connector quantity, total: 8
  • Rf connector quantity, high band: 0
  • Rf connector quantity, mid band: 4
  • Rf connector quantity, low band: 4
