294572

Base product: ANGLE-ADAPTER-SERIES

Angle Adapter, 3/8 in tapped hole

Finish making your selections or clear them to view relevant specifications.
Download specifications
Find a partner

Product classification

Product Type Angle adapter
Product Brand I-Line
Ordering Note ANDREW® non-standard product

General specifications

Adapter Type Angle adapter
Mounting 3/8 in tapped hole

Dimensions

Inside Width 16.002 mm | 0.63 in
Outside Width 38.1 mm | 1.5 in
Inside Length 16.002 mm | 0.63 in
Outside Length 46.99 mm | 1.85 in
Material Thickness 2.972 mm | 0.117 in

Material specifications

Material Type Stainless steel

Mechanical specifications

Installation Torque, maximum 17.626 N-m | 13 ft lb
Installation Torque, minimum 14.914 N-m | 11 ft lb
Maximum Loading Double stack, 1-5/8 in cable

Packaging and weights

Height, packed 17 cm | 6.693 in
Width, packed 13 cm | 5.118 in
Length, packed 10 cm | 3.937 in
Packaging quantity 10
Weight, gross 1.59 kg | 3.505 lb

Regulatory compliance/certifications

Agency Classification
ROHS Compliant
UK-ROHS Compliant
REACH-SVHC Compliant as per SVHC revision on www.andrew.com/ProductCompliance

Product classification

Product Type Angle adapter
Product Brand I-Line
Ordering Note ANDREW® non-standard product

General specifications

Adapter Type Angle adapter
Mounting 3/8 in tapped hole

Dimensions

Inside Width 16.002 mm | 0.63 in
Outside Width 38.1 mm | 1.5 in
Inside Length 16.002 mm | 0.63 in
Outside Length 46.99 mm | 1.85 in
Material Thickness 2.972 mm | 0.117 in

Material specifications

Material Type Stainless steel

Mechanical specifications

Installation Torque, maximum 17.626 N-m | 13 ft lb
Installation Torque, minimum 14.914 N-m | 11 ft lb
Maximum Loading Double stack, 1-5/8 in cable

Packaging and weights

Height, packed 17 cm | 6.693 in
Width, packed 13 cm | 5.118 in
Length, packed 10 cm | 3.937 in
Packaging quantity 10
Weight, gross 1.59 kg | 3.505 lb

Regulatory compliance/certifications

Agency Classification
ROHS Compliant
UK-ROHS Compliant
REACH-SVHC Compliant as per SVHC revision on www.andrew.com/ProductCompliance
